PE coated color aluminum sheet

1,869 views 2020-10-14 15:47
  • Alloy: 1050,1060,1100,3003,3004,5052
  • Thickness: 0.2-1.0mm for coil;1.0-6.0mm for sheet
  • Width: Max 1850mm
  • Coating Thickness:15-30μm or request, one side or both sides
  • Color: RAL, Sample color request.
  • Customization: Specifications can be customized according to requirements, special sizes, shapes, surface coating colors, and installation kits can be customized according to requirements

PE coated color aluminum sheet description:

Table Of Contents SHOW

Pe coated color aluminium sheet is a new kind of material, the surface is coated with a layer of PE paint, so that the aluminum plate has uv protection, acid and alkali resistance, high weather resistance and other excellent properties.

Blue coated aluminum coil in production
Blue coated aluminum coil in production

STEK can produce according to the specifications customized by the customer. The professional PE color coating production line ensures the stable quality of the color aluminum sheet or color aluninium coil.

Marble patterned aluminum sheet
Marble patterned aluminum sheet

PE coated aluminium sheet Good mechanical system, light weight, high strength, fast installation and construction.

Select high quality aluminum, plastic, adhesive, using advanced composite technology.

This product has the bending strength and bending strength required by the decorative plate. In the climate of four seasons, the change of wind pressure, temperature, humidity and other factors will not cause bending, deformation, expansion and so on.

PE coated aluminium sheet specifications

Product Name Best stainless steel wing nut anchor bolt for construction fastener.
Material Aluminum Alloy 1100, 3003, 3004, 5052, or according to customer requirement.
Regular Thickness 1.5mm, 2.0mm, 2.5mm, 3mm, 3.5mm, 4mm Solid Aluminum Panel.
Note:According to national Standard, the actual thinkness is lee than theoretical thickness about 0.12-0.15mm.
Max Size 1500*4000mm Solid Aluminum Panel?
Note:Price is changed by different sizes, we can create them which the size is exceed such size, and the delivery time would more long.
Finish PVDF, Power coated, Anodised, woodgrain and Electrophoresis
Brand of coating PPG, Akzo Nobel, Sunroad, KCC, NOROO, etc.
Color type Solid colors, Metallic colors, Woodgrain, Marble and Rock color, etc.
Service Manufacture products in accordance with customer drawings

Aluminum sheet pre-roll coating process

Aluminum sheet pre-roll coating process
Aluminum sheet pre-roll coating process

Multi-layer painting process

Multi-layer painting process
Multi-layer painting process

Coating thickness: It can be divided into single coating (4μm-20 μm); double coating (25μm-28 μm); 3 coating (35μm-38μm).

Advantages of pe coated aluminium sheet

Compared with ordinary building boards, pe coated aluminium sheet has the following characteristics:

  1. The texture is clear and beautiful, with a sense of fashion and technology.
  2. Excellent weather resistance, no deformation, long-lasting bright as new.
  3. Strong decoration, easy installation, wide application.
stone-like aluminum panel with quartz design
stone-like aluminum panel with quartz design

The performance of PE color coated coil/sheet

Thickness≤0.5mm
Item Test Item Standard National standard Test Result
1 Color Difference ECCA T3 ΔE≤2.0 ΔE≤1.5
2 Gloss Difference ECCA T2 ≤10 ≤5
3 Coating Thickness ECCA T1 Min 14μm ≥16μm
4 Pencil Hardness ASTM D3363 ≥HB HB
5 T-bend ASTM D4145 ≤3T ≤2T
6 Adhesion ASTM D3359 Grade 0 Grade 0
7 Impact ASTM D2794 ≥20kg.cm ≥20kg.cm
8 Boiling water Resistance GB/T17748 2h no change 2h no change
9 Solvent Resistance ASTM D2248 200 times paint remaining 200 times paint remaining
10 Salt Resistance ASTM B117 720 hrs≤grade 1 720hrs≤grade 1
11 Dirt Resistance GB/T9780 ≤5% ＜5%
12 Color retaining GB/T16259 600hrs △E≤2.0 △E≤2.0
13 Gloss weaken Level 600hrs ≤ grade 2 600hrs ≤ grade 2
14 Chalking 600hrs No Change No Change

Thickness＞0.5mm
Item Test Item Standard National standard Test Result
1 Color Difference ECCA T3 ΔE≤2.0 ΔE≤1.5
2 Gloss Difference ECCA T2 ≤10 ≤5
3 Coating Thickness ECCA T1 Min 14μm ≥18μm
4 Pencil Hardness ASTM D3363 ≥HB HB
5 T-bend ASTM D4145 ≤3T ≤2T
6 Adhesion ASTM D3359 Grade 0 Grade 0
7 Impact ASTM D2794 ≥50kg.cm ≥50kg.cm
8 Boil Resistance GB/T17748 2hrs No change 2hrs No change
9 Solvent Resistance ASTM D2248 200 times paint remaining 200 times paint remaining
10 Salt Resistance ASTM B117 720hrs ≤ grade 1 720hrs ≤ grade 1
11 Acidity Resistance GB/T9780 ≤5% ＜5%
12 Color retention GB/T16259 600hrs △E≤2.0 △E≤2.0
13 Gloss weaken Level 600hrs ≤grade 2 600hrs ≤ grade 2
14 Chalking No change No change

Application of pe coated aluminium sheet

Pe coated aluminium sheet are widely used in architectural decoration, food packaging, electronic appliances, printing, transportation and other fields.

Case of STEK color aluminum

Some decorative case effects of STEK Color Aluminum
Some decorative case effects of STEK Color Aluminum

Pe coated color aluminium sheet is made of high-strength aluminum alloy substrate after deester, cleaning and passivation layer treatment.

On this basis, it is coated with PE coating to make the aluminum plate durable.

The surface pretreatment is to remove the oil and dirt on the surface of the hanging board or profile, and to remove the loose oxide layer naturally formed on the surface of the aluminum base, so as to form a layer that is firmly bonded to the aluminum base and can be combined with Polyethylene .

Embossed aluminum panel with cloth texture
Embossed aluminum panel with cloth texture

STEK color aluminum pre-coating workshop

STEK color aluminum pre-coating workshop
STEK color aluminum pre-coating workshop

Trade show

expositions
expositions

Certificate of STEK Color Aluminum

Certificate of STEK Color Aluminum
Certificate of STEK Color Aluminum

The coating of pe coated aluminium sheet has many excellent characteristics such as antibacterial, long life, anti-fading, high strength, antistatic, high weather resistance etc .

We also produce 3d wood grain effect, imitation wood grain, wooden, silver, blue sky pattern, green grass pattern, imitation brick pattern, camouflage pattern and other color coated aluminum coil products.

PE coated aluminium sheet is a new decorative material, widely used, recyclable, is the preferred material to replace steel galvanized coated plate,high product quality better than the national standard, factory price;We also produce Gray, iron gray, white gray, silver gray, dark gray, red, black, imitation copper, sand effect and other color coating aluminum coil products, welcome to contact us for accurate pe coated aluminium sheet prices and free sample.
